The general building hoist manufactured by our company have the features such as good quality, long life, wide application range and convenient for maintenance. The gearing adopt imported bearing, enameled cable, and oil seal. the electric parts adopt products from world renowned manufactures such as Schneider, Siemens and LG. The racks and pinion adopts special material and heat treatment technique, which prolong the life of these parts. The steel structure uses quality steel from famous domestic manufactures. The surface of the structure can be produced and decorated by steel knitted mesh, aluminum molded board, punched plate or figured aluminum board.
Main technical data |
Unit |
Value |
|---|---|---|
| Rated loadeddd | kg | 2×2000 |
| Rated load | kg | 2×2000 |
| Rated erection load | kg | 2×1000 |
| Jib attachment rated load | kg | 300 |
| Cage size | m | 3.0×1.3×2.5 |
| Maximum lifting height | m | 250 |
| Rated load | kg | 2×2000 |
| Lifting speed | m/min | 36 |
| Rated output | kW | 2×3×11 |
| Voltage rating | V | 380/440 |
| Rated frequency | Hz | 50/60 |
| Rated current | A | 2×3×23.5 |
| Power supply fuses | A | 2×96 |
| Protective class | / | IP55 |
| Load duration factor | / | FC-25% |
| Safety device | m/s | 1.2 |
| Rated frequency | Hz | 50/60 |
| Enclosure weight | Kg | 1480 |
| Cage weigh | kg | 2×1950 |
| Counterweight | kg | / |
| Mast section weight | kg | 150/170/190 |
| Mast section length | mm | 1508 |
