Weight includes the weigh of platforms, hoists, safety breakers and electrical control systems. We proudly achieved 80% market share in Qatar by catering a good quality and excellent after sales services through our highly qualified and trained operation team. We are capable to apply any requirements, provide the best solution and support in this sector.
Model |
ZLP500 |
ZLP630 |
ZLP800A |
ZLP800B |
ZLP1000A |
|---|---|---|---|---|---|
| Rated Capacity | |||||
| Rated Capacity | 500 KG | 630 KG | 800 KG | 800 KG | 1000 KG |
| Rated Speed | |||||
| Rated Speed | 9- 11m/min | 9- 11m/min | 9- 11m/min | 9- 11m/min | 8- 10m/min |
| y Platform Length | |||||
| Platform Length | 5m | 6m | 7m | 7m | 7m |
| Steel Rope | |||||
| Steel Rope | 8.3 mm 4x31SW+Fc-8.3 |
8.3 mm 4x31SW+Fc-8.3 |
8.3 mm 6x19+IWS-8.6 |
8.3 mm 4x31+Fc-8.6 |
8.3 mm 6x19IWS-8.6 |
| Rated Lifting Force | |||||
| Rated Lifting Force | 4.9kN | 6.7kN | 7.84kN | 7.84kN | 9.8kN |
| Power | 1.5kWx2 | 1.5kWx2 | 2.2kWx2 | 1.8kWx2 | 3.0kWx2 |
| Voltage/frequency | 380v/60Hz | 380v/60Hz | 380v/60Hz | 380v/60Hz | 380v/60Hz |
| Speed | 1420rpm | 1420rpm | 1420rpm | 1420rpm | 1420rpm |
| Breake Force Moment | 15Nm | 15Nm | 15Nm | 15Nm | 30Nm |
| Permission Force of Impmact | 30kN | 30kN | 30kN | 30kN | 30kN |
| Locking Cable Angle | 3~8 | 3~8 | 3~8 | 3~8 | 3~8 |
| Front Beam Overhang | 1.3m~1.7m | 1.3m~1.7m | 1.3m~1.7m | 1.3m~1.7m | 1.3m~1.7m |
| Height Adjustment | 1.365m~1.925m | 1.365m~1.925m | 1.365m~1.925m | 1.365m~1.925m | 1.365m~1.925m |
| Weight | 310kg | 310kg | 310kg | 310kg | 390kg |
| Counter Weight | 750kg | 750kg | 1000kg | 1000kg | 11300kg |
